438 Agilent E5505A User’s Guide
19
PC Components Installation
Default GPIB addresses
Table 74 shows the default GPIB address for each instrument in the system.
5
Select Next.
6
In the Set Model & Serial Numbers box (Figure 328):
a
Type II PCI20428W-1 in the Asset Name box.
b
Type the serial number for your PC Digitizer in the Serial Number
(optional) box.
7
Select Next.
Table 74 Default GPIB addresses
Instrument GPIB Address
Test set 20
Downconverter 28
Microwave downconverter 28
RF analyzer 17
FFT analyzer (PC digitizer card) 1
FFT analyzer (89410A) 18
Source # 1 19
Source # 2 23
Counter 3
Agilent E1430 VXI digitizer
1
1 The E5500 software supports this instrument although it is not part of the standard E5505A system.
129
Agilent E1437 VXI digitizer
1
192
Agilent E1420B VXI counter
1
48
Agilent E1441 VXI ARB
1
80
Agilent GPIB slave Port 22
CAUTION
If an address is a single digit address, for example (3), do not add a leading zero
(03) to the address. The phase noise software treats these (3 and 03) as different
addresses.
