PC Components Installation
19
Agilent E5505A User’s Guide 427
Step 11: Install the E5500 Phase Noise Measurement software.
Use this procedure to re-install the E5500 software on your system PC.
4 The ACE display should now look like…
Step Notes
To install the E5500 software
Step Note
1 Make sure your PC and display are on and the
E5500 Phase Noise Measurement System
software DVD-R is in the PC’s DVD-R drive.
2 Navigate to the DVD-R contents folder using
the menu selections Start/Run/Browse, and
select the DVD-R drive.
•
You can also open and close the DVD-R
drive to cause a window with the DVD-R
contents folder to appear.
3 Double-click on Setup.exe.
