418 Agilent E5505A User’s Guide
19
PC Components Installation
Making Connections
1
Connect the following cables between the PC Digitizer card adapter and the
test set:
SMA (male) to BNC (male) cable between the PC digitizer card adapter’s
IN connector and the test set’s front-panel connector
ANALYZER <100 MHz OUT.
SMA (male) to BNC (male) cable between the PC digitizer card adapter’s
OUT connector and the test set’s rear-panel connector
CHIRP SOURCE IN.
2
Refer to Figure 322 below and Figure 323 on page 420 for examples of
system interconnections.
Table 73 E5505A connectors and adapters
Part
Number
Description N5500A
Standard
N5500A
Opt. 001
N5500A
Opt. 201
N5501A
N5502A
N5507A N5508A N5508A
Opt. 002
0960-0053 Termination, coaxial SMA
(male), 50 Ω
433
1250-0207 Termination, BNC, 50 Ω 111
1250-0780 Adapter, Type N (male) to BNC
(female)
3231
1250-0839 Termination, coaxial SMC
(female), 50 Ω
111
1250-1200 Adapter, SMA (male) to BNC
(female)
2
1250-1250 Adapter, N (male) to SMA
(female)
121
1250-2015 Adapter, SMA (female) to BNC
(male)
1
1250-2076 Termination, coaxial SMB
(female), 50 Ω
111
5061-5311 Adapter/Connector saver, 3.5
mm (female) to 3.5mm (female)
22 312
5813-0803 GPIB extension 1 with E5505A System, or 2 for use with Agilent Technologies E5500 SCPI
Remote Interface GPIB slave Port
E5505-60001 Digitizer adapter for PC 1 with E5505A system
NOTE
For easy re-installation, label each end of the cables with the corresponding instrument
connectors.
