402 Agilent E5505A User’s Guide
18
System Interconnections
4
Connect cables to other instruments with the appropriate connectors and
adapters, using the tables and diagrams in this section. (Refer to Figure 307
on page 403 through Figure 309 on page 405.)
• Install a GPIB extension on these system instruments before connecting
the GPIB cable: N5500A/01A/02A/07A/08A.
5
You may connect other assets (in addition to those supplied with the
system) either at this time or after running the confidence test.
6
Lastly, connect the power cord(s) to the AC power supply.
CAUTION
Do not make a GPIB connection with an oscilloscope. Doing so causes the E5505A
system to malfunction and may result in damage.
NOTE
For easy re-installation, label each end of each cable with the corresponding instrument
connector names.
