390 Agilent E5505A User’s Guide
17
System Specifications
Specifications
This section contains mechanical and environmental specifications, operating
characteristics, power requirements, and PC requirements for the system. It
also provides specifications for accuracy, measurement qualifications, and
tuning.
Table 66 contains the mechanical and environmental specifications for a
system. Table 67 shows the system’s operating characteristics.
Table 66 Mechanical and environmental specifications
Specifications Values
Temperature:
Operating
Non-operating/storage
0 °C to 40 °C (32 °F to 131 °F)
-40 °C to 70 °C (-40 °F to 158 °F)
Altitude type tested from 0 to 3000 m (9,842 ft) - operating
4600 m (15,000 ft) - non-operating
Relative humidity type tested at 95%, +40°C (non-condensing)
Air flow space required 102 mm (4 in) on all sides
System weight: Benchtop 1.6 Meter Rack 2 Meter Rack
Approximate, typical 210 lbs (95.5 kg) 431 lbs (195.5 kg) 465 lbs (211 kg)
System dimensions:
Height
Width
with rack-mounted flat-panel display
with benchtop PC and display
Depth
711 to 915 mm (28 to 36
in)
432 mm (17 in)
n/a
1,016 mm (40 in)
711 mm (28 in)
1,620 mm (64 in)
600 mm (23.6 in)
1438 mm (56.7 in)
n/a
905 mm (35.7 in)
2,020 mm (79.5 in)
600 mm (23.6 in)
1438 mm (56.7 in)
n/a
905 mm (35.7 in)
Table 67 Operating characteristics
Warm up time required 30 minutes
Carrier frequency ranges 50 KHz to 1.6 GHz
50 KHz to 6 GHz
50 KHz to 18 GHz
50 KHz to 26.5 GHz
Offset frequency ranges 0.01 Hz to 2 MHz
0.01 Hz to 100 MHz
System noise response –180 dBc/Hz typically (>10 kHz offsets)
System spurious response ≤120 dBc typically
