Reference Graphs and Tables

8664A Frequency Limits

8664A mode keys

• The [Mode 2] key provides a median range of FM deviation and RF output

switching time, as shown in Table 61.

• The [Mode 3] key provides the lowest noise level at the RF output, FM

deviation bandwidth is narrower, and the RF switching time is slower than

in either Modes 1 or 2.

Table 60 8664A frequency limits

Note: Special Function 120 must be enabled for the

DCFM

Minimum Recommended PTR (Peak Tune Range)

PTR =FM Deviation x VTR

Takes into account limited tuning resolution available in linear FM (Special Function 120, refer to “How to access special

functions"

on page 375

Model

Number

Option Band Minimum

(MHz)

Band Maximum

(MHz)

Mode 3 Mode 2

8664A 2060 3000 400000 10000000

8664A 1500 2059.99999999 200000 10000000

8664A 1030 1499.99999999 200000 5000000

8664A 750 1029.99999999 100000 5000000

8664A 515 749.99999999 100000 2500000

8664A 375 514.99999999 50000 2500000

8664A 257.5 374.99999999 50000 1250000

8664A 187.5 257.49999999 25000 1250000

8664A 30 187.49999999 200000 5000000

8664A 5 29.99999999 100000 5000000

8664A 0.05 4.99999999 Max FM = MIN (Above, Carrier frequency –9 kHz)

Table 61 Operating characteristics for 8664A modes 2 and 3

Characteristic Synthesis Mode

Mode 2 Mode 3

RF Frequency Switching Time 200 ms 350 ms

FM Deviation at 1 GHz 1 MHz 100 kHz

Phase Noise (20 kHz offset at 1 GHz) -130 dBc -136 dBc
