Reference Graphs and Tables
16
Agilent E5505A User’s Guide 373
Tuning Characteristics of Various VCO Source Options
Table 55 Tuning parameters for several VCO options
VCO Source Carrier
Freq.
Tuning Constant
(Hz/V)
Center
Voltage (V)
Voltage Tuning
Range (
±
V)
Input
Resistance
(
Ω)
Tun ing
Calibration
Method
Agilent 8662/3A
•
EFC
•
DCFM
υ
0
5 E – 9 x υ
0
FM Deviation
0
0
10
10
1E + 6
1 k (8662)
600 (8663)
Measure
Calculate
Calculate
Agilent 8642A/B FM Deviation 0 10 600 Calculate
Agilent 8643A/44B FM Deviation 0 10 600 Calculate
Agilent 8664A
Agilent 8665A/B
FM Deviation 0 5
(See Caution
Below)
600 Calculate
Other Signal Generator
DCFM Calibrated for
±1V
FM Deviation 0 10 R
in
Calculate
Other User VCO Source Estimated
within a factor
of 2
–10 to +10 See “Tune Range of
VCO for Center
Voltage" on
page 369
1 E + 6 Measure
CAUTION
Exceeding 5 volts maximum voltage tuning range for the 8664A and 8665A/B may
damage equipment.
