364 Agilent E5505A User’s Guide
16
Reference Graphs and Tables
Phase Noise Level of Various Agilent Sources
The graph in Figure 290 indicates the level of phase noise that has been
measured for several potential reference sources at specific frequencies.
Depending on the sensitivity that is required at the offset to be measured, a
single reference source may suffice or several different references may be
needed to achieve the necessary sensitivity at different offsets.
Figure 290 Noise level for various reference sources
E5505a_user_phase_noise_levels
17 Mar 04 rev 3
8657A/B
8644B
ESG with Opt 1E5
8664A/65A/65B Opt 004
