36 Agilent E5505A User’s Guide
2
Introduction and Measurement
Powering the System On
This section provides procedures for powering on a racked or benchtop
system. First connect your system to an appropriate AC power source, then
follow the steps below.
To power on a racked system
1
Press the system power switch (front, top right of the rack) to the on
position.
2
Verify that all instrument power switches are on.
3
Allow the system to warm up for 30 minutes.
To power on a benchtop system
1
Press the power switch on each instrument to the on position.
2
If you have the system connected to a safety power strip, turn the strip’s
power switch to the on position.
3
Allow the system to warm up for 30 minutes.
WARNING
Before applying power, make sure the AC power input and the location of the
system meet the requirements given in Chapter 17, “System Specifications.”
Failure to do so may result in damage to the system or personal injury.
NOTE
Warm-up Time: The downconverter and RF source instruments contain ovenized
oscillators which must warm up for 30 minutes to produce accurate measurements.
Standby Mode: The RF source uses a standby mode to keep the ovenized oscillator warm
when the instrument is connected (plugged in) to AC power, even when the power switch
is in the off position. To completely shut down the instrument, you must disconnect it from
the AC power supply.
