310 Agilent E5505A User’s Guide
12
AM Noise Measurement Examples
CAUTION
The test set’s signal input is subject to the limits and characteristics in Tab l e 47 on
page 311.
To prevent damage to the test set’s hardware components, do not apply the input
signal to the test set’s signal input connector until the input attenuator (Option
001) has been set by the phase noise software, which will occur when the
connection diagram appears.
