288 Agilent E5505A User’s Guide
11
AM Noise Measurement Fundamentals
AM detector
Figure 219 AM Noise system with 70429A Opt K21 AM detector
Figure 220 AM noise system with N5507A downconverter
DUT
AM detector Option K21
Noise
input
Test set
DUT
Microwave
downconverter
Noise
input
AM noise
output
Test set
Signal
input
Figure 221 AM detector schematic
E5505a_am_detector_schemo
01 Mar 04 rev 1
K21
polarity
switch
511
RF
input
AM
detector
output
Diode
detector
10n
2600 μF
at 25V
