FM Discriminator Measurement Examples
10
Agilent E5505A User’s Guide 277
Refer to Figure 210 on page 278 for more information about system
interconnections.
CAUTION
The test set’s signal input is subject to the limits and characteristics contained in
Tab l e 44 on page 277.
To prevent damage to the test set’s hardware components, do not apply the input
signal to the test set’s signal input connector until the input attenuator (Option
001) has been set by the phase noise software, which occurs at the connection
diagram.
Table 44 Test set signal input limits and characteristics
Limits
Frequency
•
50 kHz to 1.6 GHz (Std.)
•
50 kHz to 26.5 GHz (Option 001)
•
50 kHz to 26.5 GHz (Option 201)
Maximum Signal Input Power Sum of the reference and signal input power
shall not exceed +23 dBm
At Attenuator Output, Operating Level Range:
•
RF Phase Detectors 0 to +23 dBm (Signal Input)
+15 to +23 dBm (Reference Input)
•
Microwave Phase Detectors 0 to +5 dBm (Signal Input)
+7 to +10 dBm (Reference Input)
•
Internal AM Detector 0 to +20 dBm
Downconverters:
•
Agilent N5502A/70422A 0 to +30 dBm
•
Agilent N5507A/70427A +5 to +15 dBm
Characteristics
Input Impedance 50 Ω nominal
AM Noise DC coupled to 50 Ω load
