238 Agilent E5505A User’s Guide

Residual Measurement Examples

CAUTION

The test set’s signal input is subject to the limits and characteristics contained in

Tab l e 36 .

To prevent damage to the test set’s hardware components, do not apply the input

signal to the test set’s signal input connector until the input attenuator (Option

001) has been set by the phase noise software, which occurs at the connection

diagram.

Table 36 Test set signal input limits and characteristics

Limits

Frequency

•

50 kHz to 1.6 GHz (Std)

•

50 kHz to 26.5 GHz (Option 001)

•

50 kHz to 26.5 GHz (Option 201)

Maximum Signal Input Power Sum of the reference and signal input power shall not

exceed +23 dBm (+30 dBm for

Option 001)

At Attenuator Output, Operating Level

Range:

•

RF Phase Detectors 0 to +23 dBm (Signal Input)

+15 to +23 dBm (Reference Input)

•

Microwave Phase Detectors 0 to +5 dBm (Signal Input)

+7 to +10 dBm (Reference Input)

Characteristics

Input Impedance 50 Ω nominal

NOTE

Refer to the following system connect diagram examples in Chapter 18, “System

Interconnections” for more information about system interconnections.

•

Figure 307, “E5505A system connections with standard test set,” on page 403

•

Figure 308, “E5505A system connections with test set option 001,” on page 404

•

Figure 309, “E5505A system connections with test set option 201,” on page 405
