230 Agilent E5505A User’s Guide

Residual Measurement Examples

Amplifier Measurement Example

This example contains information about measuring the residual noise of

two-port devices. It demonstrates a residual phase noise measurement for an

RF Amplifier. Refer to Chapter 7, “Residual Measurement Fundamentals for

more information about residual phase noise measurements.

Required equipment

This measurement requires the following equipment:

• RF amplifier

• Stimulus source (frequency of amplitude under test)

• Power splitter (NARDA 30183)

• Coaxial cables and adapters necessary to connect the DUT and reference

source to the test set.

The setup for a residual phase noise measurement uses a phase shifter to set

quadrature at the phase detector. See Figure 162 on page 231.

CAUTION

To prevent damage to the test set’s components, do not apply the input signal to

the signal input connector until the input attenuator has been correctly set for the

desired configuration, as show in Tab l e 36 on page 238. Apply the input signal

when the connection diagram appears.

NOTE

To ensure accurate measurements allow the DUT and measurement equipment to warm

up at least 30 minutes before making the noise measurement.
