Residual Measurement Fundamentals

Agilent E5505A User’s Guide 217

The system software will then prompt you to set the phase noise software’s

meter to quadrature.

The system will now measure the noise data.

Measured beatnote

This calibration option requires that one of the input frequency sources be

tunable such that a beatnote can be acquired from the two sources. For the

system to calibrate, the beatnote frequency must be within the following

ranges shown in Table 31.

Advantages

• Simple method of calibration.

Disadvantages

• It requires two RF sources, separated by 0.1 Hz to 50 MHz at the phase

detector. The calibration source output power must be manually adjusted to

the same level as the power splitter output it replaces (requires a power

meter).

Table 31 Frequency ranges

Carrier Frequency Beatnote Frequency Range

<500 kHz 10 Hz to 10 kHz

<5 MHz 10 Hz to 100 kHz

<50 MHz 10 Hz to 1 MHz

<250 MHz 10 Hz to 10 MHz

>250 MHz 10 Hz to 50 MHz

or 1/2 the frequency range of the configured analyzer, or whichever is lower.
