Absolute Measurement Examples

Agilent E5505A User’s Guide 197

Estimate the system’s capture range (using the VCO source parameters

entered for this measurement) using the equation below. The estimated VCO

tuning constant must be accurate within a factor of 2.

Making the measurement

Click the Continue button when you have completed the beatnote check

and are ready to make the measurement.

When the PLL Suppression Curve dialog box appears, select View

Measured Loop Suppression, View Smoothed Loop Suppression, and

View Adjusted Loop Suppression. See Figure 141 on page 198.

NOTE

If you are able to locate the beatnote, but it distorts and then disappears as you adjust it

towards 0 Hz, your sources are injection locking to each other. Set the beatnote to the

lowest frequency possible before injection locking occurs and then refer to Minimizing

Injection Locking in the Problem Solving section of this chapter for recommended actions.

NOTE

If you are not able to tune the beatnote to within the capture range due to frequency drift,

refer to Tracking Frequency Drift in the Problem Solving section of this chapter for

information about measuring drifting signals.

)________(

(V) X (Hz/V)

)(

(V) Range Tuning X (Hz/V)Constant TuningVCO

)(

HzHzRangeCapture

HzRangeCapture
