182 Agilent E5505A User’s Guide

Absolute Measurement Examples

Checking the beatnote

While the connect diagram is still displayed, Agilent recommends that you use

an oscilloscope (connected to the Monitor port on the test set) or a counter to

check the beatnote being created between the reference source and your

device-under-test. The objective of checking the beatnote is to ensure that the

center frequencies of the two sources are close enough in frequency to create a

beatnote that is within the capture range of the system.

The phase lock loop (PLL) capture range is 5% of the peak tuning range of the

VCO source you are using. (The peak tuning range for your VCO can be

estimated by multiplying the VCO tuning constant by the tune range of VCO.

Table 24 Test set signal Input Limits and Characteristics

Limits

Frequency

•

50 kHz to 1.6 GHz (Std)

•

50 kHz to 26.5 GHz (Option 001)

•

50 kHz to 26.5 GHz (Option 201)

Maximum Signal Input Power Sum of the reference and signal input power

shall not exceed +23 dBm(+30 with Option 001)

At Attenuator Output, Operating Level Range:

•

RF Phase Detectors 0 to +23 dBm (Signal Input)

+15 to +23 dBm (Reference Input)

•

Microwave Phase Detectors 0 to +5 dBm (Signal Input)

+7 to +10 dBm (Reference Input)

•

Internal AM Detector 0 to +20 dBm

Downconverters:

•

Agilent N5502A/70422A +5 to +15 dBm

•

Agilent N5507A/70427A 0 to +30 dBm

Characteristics

Input Impedance 50 Ω nominal

AM Noise DC coupled to 50 Ω load

NOTE

Refer to the following system connect diagram examples in Chapter 18, “System

Interconnections,” for more information about system interconnections.

•

Figure 307, “E5505A system connections with standard test set,” on page 403

•

Figure 308, “E5505A system connections with test set option 001,” on page 404

•

Figure 309, “E5505A system connections with test set option 201,” on page 405
