Absolute Measurement Examples
6
Agilent E5505A User’s Guide 135
If the output amplitude of your DUT is not sufficient to provide an adequate
measurement noise floor, it is necessary to insert a low-noise amplifier
between the DUT and the test set. Refer to “Inserting a Device" on page 122 for
details on determining the amplifier noise effect on the measured noise floor.
Figure 88 Noise floor for the stable RF oscillator measurement
Figure 89 Noise floor calculation example
-140 -160 -170 -180-150
Expected phase noise floor of system (dBc/Hz)
f 10kHz
R Port signal level (dBm)
-15
+15
-5
+5
n5505a_exp_phase_noise
25 Feb 04 rev 1
L Port level +15dBm
