Absolute Measurement Fundamentals

Agilent E5505A User’s Guide 119

As long as these qualifications are met, and the software does not indicate any

difficulty in establishing its calibration criteria, an increase in PTR will not

degrade the system’s measurement accuracy.

The following methods may be considered for increasing or decreasing the

PTR.

Voltage controlled oscillators

Select a different VCO source that has the tuning capabilities needed for the

measurement.

Increase the tune range of the VCO source.

Signal generators

If you are using a signal generator with a calibrated 1 Vpk DC FM Input

(such as the Agilent 8640B, 8642A/B, 8656B, or 8662/3), the Voltage tuning

Range can be increased to 10 V as long as you select Computed from the

expected T. Constant in the Calibration Process display. These signal

generators continue to meet all of the previously mentioned tuning

qualifications across a 10 V tuning range.

Increase the signal generator’s frequency deviation setting and set the

software to measure the new tuning constant or enter the increased

deviation if it is known. (Note that increasing the deviation setting often

increases the source’s noise level as well.)

If you are using a synthesizer with Electronic-Frequency-Control (EFC)

capability such as the Agilent 8662A or Agilent 8663A, it is possible to

increase the tuning range of these sources using a VCO as an external time

base. When a compatible VCO source is connected to the EXT INPUT on the

8662/3, the tuning capability of the VCO source is transferred to the

synthesizer.

CAUTION

Be careful not to exceed the input voltage limitations of the Tune Port on the VCO

source

NOTE

Increasing the tune range of the VCO is only valid as long as the VCO source is able to

continuously meet the previously mentioned tuning qualifications.
