To get updated help and program files via the Internet
The latest versions of the help and example program files are available via
anonymous ftp. You must have a connection to the Internet and have ftp
software.
1
Log on to your Internet service.
2 Connect to host col.hp.com using anonymous ftp.
A sample set of commands might be as follows:
$ ftp col.hp.com
Name: anonymous
Password: myname@mycompany.com
3 Change to the directory containing HP 54645 files.
ftp> cd dist/hp54600/hp54645
4 Get sample programs or updated help files from the directory as
desired.
For example, if you want the latest version of the HP 54645A/D Oscilloscopes
Programmer’s Reference online help file, you set the transfer mode to binary
and get the file:
ftp> binary
ftp> get hp54645.hlp
Check the README file for more information on the files in this directory.
If you have trouble making the connection, or need more information on ftp,
see your network administrator.
Installing and Using the Programmer’s Reference
To get updated help and program files via the Internet
7-4
