Chapter 5 Replaceable Parts
Replaceable Parts
242 Assembly-Level Service Guide
Replaceable Parts
Table 5-1 is a list of replaceable parts and contains the following:
• Electronic assemblies
• Chassis-mounted electrical parts
• Chassis-mounted mechanical parts
The information given for each part consists of the following:
• Counter Model Number (example, “Agilent 53230A”).
• Agilent Technologies part number.
• Total quantity (QTY) in instrument.
• Description of the part.
• Customer Order Number.
Table 5-1. Table of Replaceable Parts
Model Number
or Option
Number
Agilent Part
Number
Qty Description
Customer Order
Number
ELECTRONIC ASSEMBLIES
AGILENT 53210A 53210-66101 1 MOTHERBOARD (STANDARD TIMEBASE) 53210-66101
53210-66102 1 MOTHERBOARD (HIGH STABILITY TIMEBASE) 53210-66102
AGILENT 53220A 53220-66101 1 MOTHERBOARD (STANDARD TIMEBASE) 53220-66101
53220-66102 1 MOTHERBOARD (HIGH STABILITY TIMEBASE) 53220-66102
AGILENT 53230A 53230-66101 1 MOTHERBOARD (STANDARD TIMEBASE) 53230-66101
53230-66102 1 MOTHERBOARD (HIGH STABILITY TIMEBASE) 53230-66102
P0500-63001 1 PROCESSOR ASSEMBLY
*
53200-60002 1 FRONT PANEL BOARD 53200-60002
2090-0977 1 FRONT PANEL DISPLAY 2090-0977
OPTION 106 53200U-106 1 OPTION 106, 6.0 GHz INPUT BOARD 53200U-106 **
OPTION 115 53200U-115 1 OPTION 115, 15.0 GHz INPUT BOARD 53200U-115 **
OPTION 150 53200U-150 1 OPTION 150, MICROWAVE PULSE
MEASUREMENTS
53200U-150 **
OPTION 201 53200U-201 1 REAR PANEL PARALLEL INPUTS 53200U-201 **
