Chapter 5 Replaceable Parts
How To Order A Part
240 Assembly-Level Service Guide
How To Order A Part
Agilent Technologies wants to keep your parts ordering process as simple
and efficient as possible. To order parts perform the following steps:
1 Identify the part and the quantity you want.
2 Determine the ordering method to be used and contact Agilent
Technologies.
Parts Identification
To identify the part(s) you want, first refer to Figures 5-1 and 5-2 at the
back of this chapter. Use Table 5-1 to obtain the part number.
When ordering from Agilent Technologies, the important numbers to note
from the Parts List are the Agilent Part Number and the quantity of the
part you want.
