Chapter 5 Replaceable Parts
Contacting Agilent Technologies
Assembly-Level Service Guide 239
Contacting Agilent Technologies
Depending on where you are in the world, there are one or more ways in
which you can order parts or obtain parts information from Agilent
Technologies.
• Outside the United States, contact your local Agilent Technologies
sales office as shown in the preface of this service guide..
• Within the United States, we encourage you to order replacement
parts or request parts information directly by telephone or mail from
the Agilent Support Materials Organization, using the telephone
numbers or address listed below. You can also contact your local
Agilent Technologies Sales and Service office as shown in the preface
of this guide.
By Telephone (in the United States):
• For parts ordering, use our toll-free number, (800) 227-8164, Monday
through Friday (except Holidays), 6 a.m. to 5 p.m. (Pacific Time).
– If you need a part in a hurry, an extra-cost Hotline phone ordering
service is available 24 hours a day. Use the toll-free number above
at the times indicated; at other times, use (916) 785-8460.
• For Parts Identification Assistance, call us at (916) 783-0804.
– Our Parts Identification hours are from Monday through Friday,
6 a.m. to 5 p.m. (Pacific Time).
For mail correspondence, use the address below:
– Agilent Technologies
Support Materials Roseville
P.O.Box 1145
Roseville, CA 95661-1145
