Chapter 5 Replaceable Parts
Introduction
238 Assembly-Level Service Guide
Introduction
This chapter contains information for ordering parts.
Table 5-1 lists all replaceable assemblies and parts for the Agilent
53210A/53220A/53230A Counters.
Figures 5-1 and 5-2 show the locations of the replaceable assemblies.
This chapter contains the following sections:
• Introduction
• Contacting Agilent Technologies
• How to Order a Part
• Replaceable Parts
