Chapter 4 Retrofitting Options
To Retrofit the 53220A/53230A Channel 3 Input, 6.0 GHz (Option 106) or
15.0 GHz (Option 115) plus Rear Panel Option 203
Assembly-Level Service Guide 235
7 Line up the male SMA cable connector on the semi-rigid cable and
the Channel 3 assembly female SMA edge connector, connect
them together and tighten both of the SMA connectors using a
5/16" wrench.
NOTE If necessary, loosen the hex nut on the other end of the semi-rigid
cable to align the cable and then tighten all nuts. There should be
no stress on the semi-rigid cable.
8 Re-install the T20 TORX screw removed in step 2 above, securing
the rear flange on the Channel 3 bracket to the motherboard with
the screw.
9 Install the two supplied flathead screws through the holes in the
left-hand aluminum side panel into the embedded nuts on the
aluminum bracket of the Channel 3 assembly.
10 If removed previously, re-install the Internal Battery Assembly.
Be sure to re-connect the cables.
11 Re-install the cover by performing the cover removal procedure
(Preliminary Steps 1-4), in reverse.
12 Install the supplied Option 106 or 115 label above the rear panel
SMA connector in the location provided.
