Chapter 4 Retrofitting Options
To Retrofit the 53210A Channel 2 Rear Panel Input, 6.0 GHz (Option 106)
or 15.0 GHz (Option 115) plus Rear Panel Option 203
216 Assembly-Level Service Guide
To Retrofit the 53210A Channel 2 Rear Panel
Input, 6.0 GHz (Option 106) or 15.0 GHz
(Option 115) plus Rear Panel Option 203
Option 106/115 Channel 2 Parts
Item Agilent Part No. Qty.
• 6.0 GHz Assembly (Option 106) 53200-66505 1
• 15.0 GHz Assembly (Option 115) 53200-66506 1
• Ribbon Cable, 40-pin 53200-61605 1
• Labels, 6 GHz 53200-84301 2
• Labels, 15 GHz 53200-84302 2
• Standoff (Option 115 only) 0380-5091 2
• Bracket, Aluminum 53200-00603 1
• TORX 10 screws 0515-0430 4
• Screws, Flathead 0515-1946 2
•Screw (Option 115 only) 0515-3131 12
Option 203 Rear Panel Channel 2 Parts
Item Agilent Part No. Qty.
• RF Cable, Rear, SMA Semi-rigid 53200-61606 1
• Retainer 53200-40002 1
• Hole Plug 53200-40001 1
• Screw, Self-tapping 0515-5220 1
NOTE After the installation of Option 106 or 115, a complete Microwave
Frequency Calibration must be performed. Refer to Chapter 2 for
the procedure.
