Chapter 3 Replacing Assemblies
Tools Required
Assembly-Level Service Guide 171
Tools Required
The following tools are required for these removal and replacement
procedures:
• Hand TORX‚ 8 screwdriver (T8)
• Hand TORX‚ 10 screwdriver (T10)
• Hand TORX‚ 20 screwdriver (T20)
• 7-mm spin tight
• 14-mm deep-socket spin tight
• 1/4" spin tight
• 5/16" open end wrench
• Static-Safe Workstation
Do This First
Before performing any of the removal and replacement procedures, the
following steps must be performed.
1 Turn counter off.
2 Remove AC line power cord from the rear AC line socket.
WARNING HAZARDOUS VOLTAGES ARE ON THE POWER SUPPLY
ASSEMBLY. AFTER UNPLUGGING THE INSTRUMENT, WAIT AT
LEAST SIX MINUTES FOR THE CAPACITORS ON THE POWER
SUPPLY ASSEMBLY TO DISCHARGE BEFORE WORKING ON
THIS INSTRUMENT.
3 Open up the counter only at a Static-Safe Workstation.
