Chapter 2 Service
Pre-Troubleshooting Information
Assembly-Level Service Guide 147
# Refer to Chapter 6 “Backdating” for other information on the assemblies
inside your counter. Contact your local Agilent Technologies Service
Center for current information. Refer also to Chapter 5 “Replaceable
Parts” for other part numbers.
* Not customer-replaceable. Must return to Agilent Technologies for
replacement.
(Firmware compatibility requirements.)
** These items are not obtainable through the Agilent Parts
Organization. If these parts are defective, the instrument may be sent to
Agilent for repair. As an alternative, you may order replacement parts as
retrofit options using the provided order number. See the preface for
information on contacting Agilent.
CAUTION DO NOT swap the motherboard, the processor board, or the front
panel board from one instrument to another. These boards
contain model number and serial number information that
uniquely identifies a specific unit, and boards that are
mismatched to the instrument may result in problems with
performance, licensing, serviceability, importability/exportability
or warranty.
