4 Making Measurements
94 Agilent 3000 Series Oscilloscopes User’s Guide
Rise Time
Measures the rise time of a waveform.
Fall Time
Measures the fall time of a waveform. See Figure 42 on page 94.
Figure 41 Period and Frequency Measurements
Period
Time
origin
line
50%
Top
Base
Figure 42 Rise Time and Fall Time Measurements
Vbase
Time
origin
line
50% (middle)
90% (upper)
10% (lower)
Falling
edge
Vtop
Rising
edge
