Displaying Data 2
Agilent 3000 Series Oscilloscopes User’s Guide 37
Horizontal scale
setting
Sample
rate
Displayed waveform window ([ ])
position in memory
Trigger position
in memory
Trigger position in
waveform window
Figure 11 Status Bar, Trigger Position, and Horizontal Scale Indicators
