1Getting Started
28 Agilent 3000 Series Oscilloscopes User’s Guide
Step 6. Become familiar with the oscilloscope display
Channel 1 Status
Timebase Status
Sample Rate
Channel 1
Reference
Acquisition
Status
Waveform
Menu
Waveform window
position in memory
Trigger position
in memory
Trigger position in
waveform window
Figure 5 Oscilloscope Display
