Getting Started 1
Agilent 3000 Series Oscilloscopes User’s Guide 25
The definitions of the buttons and the knobs are as follows:
Measure controls Cursors
and Measure menu buttons.
Waveform
controls
Acquire
and Display menu buttons.
Menu controls Save/Recall
and Utility menu buttons.
Vertical controls Vertical position knobs, vertical scale knobs, channel (1
, 2) Math, and Ref
menu buttons.
Horizontal
controls
Position knob, Main/Delayed
menu button, and scale knob.
Trigger controls Trigger Level
knob, 50%, Mode/Coupling, and Force buttons.
Run controls Run/Stop
, Single, and Auto-Scale buttons.
Menu defined
buttons
Five gray buttons from top to bottom on the right-hand side of the screen,
which select the adjacent menu items in the currently displayed menu.
Entry
knob For the adjustment defined controls.
