1Getting Started
24 Agilent 3000 Series Oscilloscopes User’s Guide
Step 5. Become familiar with the Front Panel Controls
Before using the oscilloscope, familiarize yourself with the front panel
controls.
The front panel has knobs and buttons. Knobs are used most often to
make adjustments. Buttons are used for run controls and to change other
oscilloscope settings via menus.
Measure
Math
Entry knob
Measure controls
Horizontal controls
Run controls
Menu controls
Waveform controls
Vertical controls Trigger controls
Menu defined buttons
Figure 3 Front Panel
