Getting Started 1
Agilent 3000 Series Oscilloscopes User’s Guide 23
Step 4. Input a waveform
1 Input a waveform to a channel of the oscilloscope.
Use one of the supplied passive probes to input the probe compensation
signal from the front panel of the oscilloscope.
CAUTION
To avoid damage to the oscilloscope, make sure that the input voltage at the BNC
connector does not exceed the maximum voltage (300 Vrms maximum).
