7 Specifications and Characteristics
122 Agilent 3000 Series Oscilloscopes User’s Guide
Dynamic range: ±6 div
Input resistance: 1 MΩ ± 1%
Input capacitance: ~13 pF
Coupling: AC, DC, ground
BW limit: ~20 MHz
ESD tolerance: ±2 kV
DC vertical gain accuracy: 2 mV/div to 5 mV/div: ±4%
10 mV/div to 5 V/div ±3%
DC measurement
(= 16 waveform averages)
±(3% x reading +0.1 div + 1mV) when 10 mV/div or greater is
selected and vertical position is at zero
±(3% x (reading + vertical position) + 1% of vertical position +
0.2 div) when 10 mV/div or greater is selected and vertical
position is not at zero
Add 2 mV for settings from 2 mV/div to 200 mV/div
Add 50 mV for settings > 200 mV/div to 5 V/div
Table 7 Horizontal System Characteristics
Name Typical Value
Range: 2 ns/div to 50 s/div
Timebase accuracy: ±100 ppm over any time interval = 1 ms
Modes: Main, Delayed, Y-T, X-Y
Table 8 Trigger System Characteristics
Name Typical Value
Sources: Channel 1, channel 2, ac line, ext, and ext/5
Sweep: Auto and Normal
Holdoff time: 100 ns to 1.5 s
Table 6 Vertical System Characteristics (continued)
Name Typical Value
