Chapter 6: Trigger on a Sequence of Events
Save Your Work
Save Your Work
1 From the Listing File menu, select Save Configuration...
2 Go to the directory /hplogic/training/.
3 Click on the Save tab.
4 In the Filename field, type SEQUENCEVENT.
5 Click the Save button.
6 Close the Listing window by clicking File, then Close from the
menu bar.
7 Go back to the Setup window and click Close.
