Chapter 6: Trigger on a Sequence of Events
Set Up the Bus Labels
5 Click on the under J, and select Falling Edge.
Set Up the Bus Labels
1 Select the Format tab.
Now you will organize the data you are capturing by creating a label
and assigning the channels of interest to that label.
2 Click on Label1, select Rename..., and change the label name to
SCOUNT.
SCOUNT is short for state count and represents the source of the
signals.
3 Click OK.
4 To the far right of SCOUNT, click on the field showing the 16
channels of pod 1.
