Chapter 3: Introduction to Timing Analysis: Trigger on an Edge
Save Your Work
Save Your Work
Saving your work lets you reuse measurement setups. This is helpful if
you make the same measurement often.
1 From the Waveform File menu, select Save Configuration...
2 Go to the directory /hplogic/training/.
3 Click on the Save tab.
4 In the Filename field, type EDGE.
5 Click the Save button.
6 Click Close.
7 Close the Waveform window by clicking File, then Close from the
menu bar.
8 Go back to the Setup window and click Close.
