Chapter 3: Introduction to Timing Analysis: Trigger on an Edge
Load the RESET Configuration File
Load the RESET Configuration File
The RESET file defaults all settings so that you can begin the
exercises. You created the RESET file in Chapter 2.
1 Decide what to do.
• If you have just completed chapter 2, go to the next page.
• If you have reconnected the credit card board to a different
analyzer, or if you have not created a RESET file, go to chapter 2
“Before You Begin.”
• If you have just completed an exercise other than chapter 2, go to
step 2.
2 Click on the File Manager icon in the tool box.
3 Under Directories, go to the directory /hplogic/training/.
4 Under Contents of ‘training’, click on the RESET file with the
file description of the analyzer you have connected to the credit
card board.
For example, if you are using an Agilent 16717A, you will click on the
file ‘RESET.__X’ with the file description of ‘16717A_LA_Config’.
5 Click the Load tab.
6 Click Load.
7 Click Yes.
8 Click Close.
