Table Of Contents
- A Quick Tour
- Before You Begin
- Introduction to Timing Analysis: Trigger on an Edge
- Verify Pulse Widths
- Introduction to State Analysis: Trigger on an Event
- Trigger on a Sequence of Events
- Trigger on a 4 Bit Serial Pattern
- Trigger the Oscilloscope with the Timing Analyzer
- Load the RESET Configuration File
- Connect the Oscilloscope Probe and Turn the Glitch On
- Get the Analog Waveform on the Display
- Set Up the Timing Analyzer
- Set Up the Timing Analyzer to Trigger on the Glitch
- Tell the Oscilloscope When to Trigger
- Set Up the Analyzer to Arm the Oscilloscope
- Run the Timing Analyzer and Oscilloscope
- Add the Analog Waveform to the Timing Waveform
- Turn the Glitch Off
- Save Your Work
- Lesson Summary
- Using the Pattern Generator
- Load the RESET Configuration File
- Connect the Pattern Generator
- Set Up the Timing Analyzer
- Set Up the Bus Labels
- Define the Trigger Conditions: Trigger on a 1
- Set Up the Pattern Generator
- Program the Pattern Generator Output
- Start the Pattern Generator and View the Walking Ones Pattern
- Stop the Pattern Generator
- Save Your Work
- Lesson Summary
- Setting the Jumpers
- About the Credit Card Board
2
Making Basic Measurements:
a self-paced training guide
This book teaches you how to set up and make measurements with the
Agilent 16600-Series and Agilent 16700-Series Logic Analysis Systems
using the credit card board provided in this kit.
What materials do I need?
You need the following materials to make measurements using the
credit card board:
• One Agilent 16600A-Series or Agilent 16700A-Series Logic Analysis System
with a state/timing measurement module. To do chapter 8, you will also
need an oscilloscope measurement module, and to do chapter 9, you will
need a pattern generator measurement module.
• A monitor, keyboard, and mouse (unless you have the Agilent 16702A).
• This training kit (part number Agilent 16700-60007).
• Probe assembly (part number Agilent 01650-61608) or a termination
adapter (part number Agilent 01650-63203).
The examples in this manual were created using the following software
and equipment:
• Software version A.01.40.00
• 16700A mainframe
• 16717A logic analyzer card
• 16534A oscilloscope module
• 16522A pattern generator module.
