134
Chapter 9: Using the Pattern Generator
Lesson Summary
Lesson Summary
You did the following:
✓ Set up the timing analyzer.
✓ Triggered on the pattern 1.
✓ Set up the pattern generator.
✓ Programmed the pattern generator.
✓ Repetitively ran the walking ones program.
✓ Ran the analyzer and viewed the walking ones pattern.
✓ Stopped the pattern generator.
✓ Saved your work.
What’s Next?
To learn how to trigger the oscilloscope with the timing analyzer, go to
chapter 8.
