133
Chapter 9: Using the Pattern Generator
Save Your Work
Save Your Work
1 Close the Pattern Generator window by clicking Close.
2 From the Waveform File menu, select Save Configuration...
3 Go to the directory /hplogic/training/.
4 Click on the Save tab.
5 In the Filename field, type PATTERN.
6 Click the Save button.
7 Close the Waveform window by clicking File, then Close from
the menu bar.
8 Go back to the Setup window and click Close.
