132
Chapter 9: Using the Pattern Generator
Stop the Pattern Generator
Stop the Pattern Generator
1 Click on the Pattern Generator window.
2 Click the Stop button to stop the repetitive run.
NOTE: The pattern generator requires CPU time when it is running independently in
the repetitive mode. Stopping the pattern generator now will prevent other
exercises that do not use it from running slower than normal.
