130
Chapter 9: Using the Pattern Generator
Start the Pattern Generator and View the Walking Ones Pattern
Start the Pattern Generator and View the
Walking Ones Pattern
When you select Run and Repetitive, the Pattern Generator begins to
run in repetitive mode. The output is the repeating "walking ones"
pattern. You will not see this output until you switch to the timing
analyzer waveform display.
The pattern generator will run independently until you stop it by
pressing the Stop key.
1 In the Pattern Generator window, right-click on Run, and select
Repetitive to set the pattern generator to run repetitively.
2 Click Run again to begin the repetitive run.
3 Click on the Setup window of the analyzer you are using.
4 Click the Run button.
The Timing analyzer runs a single trace and automatically displays the
Waveform 1 menu in which you see the "walking ones" pattern.
5 Click the Navigate button.
6 Select the slot with the analyzer you are using, and select
Waveform.
