Chapter 8: Trigger the Oscilloscope with the Timing Analyzer
Lesson Summary
Lesson Summary
You have learned how to use the timing analyzer to trigger the
oscilloscope, and how to view the analog and digital waveforms in the
same window.
You did the following:
✓ Connected the oscilloscope and turned on the glitch.
✓ Got the analog waveform on the display.
✓ Set up the timing analyzer.
✓ Set up the timing analyzer to trigger on the glitch.
✓ Set up the oscilloscope to trigger immediately following the timing
analyzer.
✓ Armed the oscilloscope by the timing analyzer.
✓ Ran the analyzer and oscilloscope.
✓ Added the analog waveform to the timing waveform.
✓ Adjusted the intermodule skew.
✓ Saved your work.
What’s Next?
To learn about state analysis and how to make a basic state
measurements, go to chapter 5.
To learn how to use the pattern generator, go to chapter 9.
