Chapter 8: Trigger the Oscilloscope with the Timing Analyzer
Turn the Glitch Off
Turn the Glitch Off
1 Set the GLITCH jumper on the credit card board to OFF.
Save Your Work
1 From the Waveform File menu, select Save Configuration...
2 Go to the directory /hplogic/training/.
3 Click on the Save tab.
4 In the Filename field, type GLITCH.
5 Click the Save button.
6 Close the Waveform window by clicking File, then Close from
the menu bar.
7 Close the Oscilloscope window the same way you closed the
Waveform window.
8 Go back to the Setup window and click Close.
The GLITCH is set to OFF.
