2. System General Overview
The whole system is designated an AGD933 and comprises;
a) A Frequency counter
b) A Frequency generator
c) A mechanical enclosure, lined with radar absorbing material
d) A desk top pc and monitor
e) USB to serial convertor.
f) USB hi speed hub -
g) MC-116 24GHz Target Simulator Unit.
h) Miscellaneous cables
Figure 1 System Overview
2.1 Operation
With the equipment connected as shown and the bespoke AGD software loaded onto the PC, launch
the software and follow the on screen instructions. The software will then exercise the radar whose
performance parameters are required to be checked. At the end of the test the software will report as
to the radars performance when compared with known parameters.
DC Input (not
supplied)
12vdc
Chan1
Chan2
Frequency
generator
PC &
monitor
Radar
holder
Frequency
counter
Mechanical enclosure
Power
Supply
USB Hub
MC
-
116
