Little Wenlock Classic Solid Fuel Stove This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled. When using the stove in situations where children, aged and/or infirm persons are present a fireguard must be used to prevent accidental contact with the stove.
TABLE OF CONTENTS PAGE NO. 1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Fire Cement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Asbestos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LITTLE WENLOCK CLASSIC SOLID FUEL NON-BOILER STOVE INSTALLATION & OPERATING INSTRUCTIONS IMPORTANT WARNING: This stove must not be installed into a chimney that serves any other heating appliance. There must not be an extractor fan fitted in the same room as the stove as this can cause the stove to emit fumes into the room.
2300 suitable stainless steel flue liner. Where a masonry chimney is not available a proprietary type 150mm twin wall, fully insulated pipe may be used. 600 Fig.1 The pipe must terminate at a point not lower than the main ridge of adjacent outside obstructions. With such installation, access to the chimney must be provided for cleaning purposes. (See Fig.
Fig.3 VENTILATION AND COMBUSTION AIR REQUIREMENTS This appliance is rated less than 5kW. There is no additional air requirement unless a flue draught stabiliser is fitted then the air requirement is 15cm2. When calculating combustion air requirements for this appliance use the following equation: 550mm2 per each kW of rated output above 5 kW should be provided, where a flue draught stabiliser is used the total free area shall be increased by 300mm2 for each kW of rated output.
LOCATION If spillage occurs following the above operation, an additional air vent of sufficient size to prevent this occurrence should be installed. There are several conditions to be considered in selecting a location for your stove. PERMANENT AIR VENT A. Position in the area to be heated - central locations are usually best. If situated in an alcove, site as far forward as possible, to provide more heat to the room. B. Allowances for proper clearances to com bustibles.
DO NOT BURN MANUFACTURED SMOKELESS FUELS WITH THIS SUPPLEMENTARY GRATE IN PLACE AS DAMAGE AND POOR PERFORMANCE WILL RESULT. LIGHTING Check that all controls and catches are operating correctly and ensure that all flue connections are thoroughly sealed. Open the spin valve fully and pull the secondary air slide to fully open. Fig.6 PRIMARY AIR CONTROL SPIN VALVE When burning manufactured smokeless fuels, the spin valve located near the bottom of the door, controls the primary air supply to the stove.
RE-FUELLING Fig.9 When refuelling with manufactured smokeless fuel riddle the fire by connecting the grate operating tool onto the rocker connection located at the bottom front of the stove, then gently pull and push the rocker arm until all dead ash has fallen through into the ashpan. Before opening the door, open the spin valve by turning it anti-clockwise, as this will help to eliminate any smoke or fly ash resident in the combustion chamber.
SLOW BURNING CHIMNEY CLEANING To achieve slow burning when burning wood close the secondary air slide and open a few millimetres using the tool provided. Slow burning will cause the window glass to blacken and should not be used for a long period as it will leave sooty deposits in the flueways. Opening the air slide will increase the heat output and will clear the glass. Chimney and connector should be cleaned at least twice a year. Once before heating season and once after.
IMPORTANT NOTES Now that your Solid Fuel stove is installed and no doubt you are looking forward to many comforts it will provide, we would like to give you some tips on how to get the best results from your stove. 1. We would like if you could take some time to read the operating instructions/hints, which we are confident, will be of great benefit to you. 2. Do not burn fuel with a high moisture content, such as a damp peat or unseasoned timber.
Before lighting the stove check with the installer that the installation work and commissioning checks described in the installation instructions have been carried out correctly and that the chimney has been swept clean, is sound and free from any obstructions. As part of the stoves commissioning and handover the installer should demonstrate how to operate the stove correctly.
GLASS 1. How to clean: The glass will clean itself when there is sufficient heat generated by burning fuel. If a build-up of creosote occurs on the glass it may be due to draft conditions, poor quality fuel or very slow burning for along time. Only clean glass when the stove is thoroughly cooled. Clean with a liquid detergent taking care not to scratch the glass with any coal ash deposits. 2. Glass Replacement: (See Fig.12) a. Open the door fully. b.
LITTLE WENLOCK SOLID FUEL STOVE EXPLODED VIEW Item No. Description Item No.
