Technical data
NATURAL G20
MAXIMUM HEAT INPUT 4.4 kW
Thermostat Bypass Size 110
Main Burner Injector 400
Pilot Injector 7218
Inlet Pressure (EU COUNTRIES ONLY) 20mbar
Burner Pressure 10 mbar (4” w.g.)
PROPANE G31
MAXIMUM HEAT INPUT
5kW (357g/h)
Thermostat Bypass Size 65
Main Burner Injector 170
Pilot Injector 4209
Inlet Pressure (EU COUNTRIES ONLY) 37mbar
Burner Pressure 25mbar (10” w.g.)
ELECTRICAL SUPPLY: 230V 50Hz 3A FUSED
AGA GC3 COOKER (AIMS)
TECHNICAL DATA (CONTINUED)
7
FLUE SYSTEM
The following notes are intended to give general guidance:-
The initial length of flue pipe from the appliance flue socket should be vertical for at least 600mm.
In any event, the minimum flue length must not be less than 3m.
The cross-sectional area of the flue serving the cooker must not be less than the area of the flue
outlet of the cooker.
If the flue pipe is to be used then, it must not be less than 100mm internal diameter.
Flue pipes and fittings should be constructed from one of the following materials:-
a) Cement
b) Aluminium or Stainless Steel
c) Cast iron or mild steel, acid resistant vitreous enamel lined
If a chimney is to be used it preferably should be one that is composed of or lined with non-
combustible porous acid resistant material. (Chimneys lined with salt glazed earthenware pipes
are acceptable if pipes comply with the regulations in force). A flue pipe constructed from one of
the materials in (a) to (c) above, should form the initial connection to lined chimneys. Where a
chimney is to be used which is not composed of or lined with a non-porous acid resistant material
it should be lined with a stainless steel flexible flue liner. The internal diameter of the liner must
not be less than 100mm. A flue pipe which is constructed from of the materials in (a) to (c) above
should form the connection between the draught diverter and flue liner.
Before connecting the appliance to or inserting a liner into, a flue that has been previously used,
the flue must be thoroughly swept clean of any soot and loose material. If a baffle is fitted in the
flue it must be removed before connecting the appliance to, or inserting a liner into the flue. The
point of termination must not be within 600mm of an openable window, air vent or any other
ventilation opening.
