Specification Sheet

Rio LED Sconce
RIS Series
Features
This simple style with elegant geometry features a frosted white acrylic diffuser
with a floating square junction box cover plate. The single arm (21-1/2” tall)
and the dual arm (32-1/2” tall) are both ADA compliant. The dual version
can also be used for vanity applications. The acrylic is retained with threads
for a tight clean appearance against the housing. This product is ideal for
corridor and accent applications.
Construction
The frosted white acrylic diffuser is mounted into a 1/8” thick die cast
fitter. Wall plate is stamped steel and held in place with 2 screws located
within the floating recess. Power supply connections must be made inside
a junction box (not included). Fixture mounts to standard junction box with
plaster ring (not included).
Finish
All exposed metal parts are plated satin nickel with a clear lacquer topcoat.
Diffuser
Diffuser is .316” thick frosted white acrylic diffuser.
Electrical
This unit it direct wired with a constant current LED driver rated for 120VAC.
Compatible with residential TRIAC and ELV dimming.
Lamping
Fixture includes an LED module producing:
2700K or 3000K (CCT)
8W = 800 source lumens
16W = 1600 source lumens
Rated for 50,000 hrs., 90 CRI
Certification
All fixtures are cULus listed for damp locations.
ADA
Warranty
Limited warranty: This fixture is free from defects in
materials and workmanship for a period of
5 years from date of purchase.
Specifications and dimensions
subject to change without notice.
2345 N. Ernie Krueger Circle • Waukegan, IL. 60087 • P: 847.249.5970 • F: 847.249.2618 • AFXinc.com R0/16
DATE
LOCATION
PREPARED
BY
COMMENTS
CATALOG
NUMBER
QUANTITY
FIXTURE TYPE
32
1
2
"
4"
3
5
8
"
4"
21
1
2
"
16
1
4
"
MC
3
5
8
"
MC - Mounting Center
Ordering Information:
Source
Satin Nickel
LED Lumens CCT H W D
RIS21800L27D1SN
8W 800 2700K 21-1/2” 4” 3-5/8”
RIS21800L30D1SN
8W 800 3000K 21-1/2” 4” 3-5/8”
RIS321600L27D1SN
16W 1600 2700K 32-1/2” 4” 3-5/8”
RIS321600L30D1SN
16W 1600 3000K 32-1/2” 4” 3-5/8”
